HP 635n - JetDirect IPv6/IPsec Print Server Administrator's Manual page 88

Table 4-12 Miscellaneous Settings (continued)
Item
9100 Config
FTP Printing
LPD Printing
IPP Printing
HP XML Services
Web Services Print
WS-Discovery
Link settings
Locally Administered Address
Syslog Facility
78 Chapter 4 Embedded Web Server (V.36.xx)
Description
NOTE: If this parameter is disabled, other protocols that use multicast protocols,
such as Bonjour and SLP, may also be disabled without notification.
Enable or disable port 9100 services. Port 9100 is an HP-proprietary raw TCP/IP port on
the HP Jetdirect print server and is the default port for printing. It is accessed by HP
software (for example, the HP Standard Port).
Enable or disable File Transfer Protocol services available on the HP Jetdirect print server
for printing. For more information, see
Enable or disable the Line Printer Daemon services on the HP Jetdirect print server. LPD
on the HP Jetdirect print server provides line printer spooling services for TCP/IP systems.
For more information, see LPD Printing on page
Enable or disable the Internet Printing Protocol on the HP Jetdirect print server. If the printer
is properly connected and accessible, IPP allows printing to this device over the Internet
(or intranet). A properly configured IPP client system is also required. For information on
IPP client software, see HP Software Solutions Summary on page
Enable or disable access by HP Web service applications to XML-based data on the HP
Jetdirect print server.
Enable or disable the Microsoft Web Services for Devices (WSD) Print services supported
on the HP Jetdirect print server.
Enable or disable the Microsoft Web Services Dynamic Discovery (WS Discovery)
protocols on the print server.
(For wired 10/100/1000T Ethernet) Sets the print server's link speed (10, 100, 1000 Mbps)
and communication mode (Full- or Half-Duplex). The available link-speed selections
depend on the print server model. The selections that may be displayed are listed below.
CAUTION: If you change the link setting, network communications with the print
server and network device may be lost.
●
AUTO (default): The print server uses auto-negotiation to configure itself with the
highest link speed and communication mode allowed. If auto-negotiation fails, either
100TX HALF or 10TX HALF is set depending on the detected link speed of the hub/
switch port. (A 1000T half-duplex selection is not supported.)
●
10T-Full: 10 Mbps, Full-duplex operation.
●
10T-Half: 10 Mbps, half-duplex operation.
●
100TX-Full: 100 Mbps, full-duplex operation.
● 100TX-Half: 100 Mbps, half-duplex operation.
●
100TX-AUTO: Limits auto-negotiation to a maximum link speed of 100 Mbps.
● 1000T FULL: 1000 Mbps, full-duplex operation.
Specifies a locally administered address (LAA) that replaces the factory-assigned LAN
Hardware (MAC) address. If LAA is used, a user-specified string of exactly 12 hexadecimal
digits must be entered.
For Ethernet print servers, the LAA address must start with hexadecimal X2, X6, XA, or
XE, where X is any hexadecimal digit 0 through F.
The default address is the factory assigned address.
Specify the encoded source facility of a message (for example, to identify the source of
selected messages during troubleshooting). By default, the HP Jetdirect print server uses
FTP Printing on page 165.
153.
9.
