Chapter 17 Upgrading, Downgrading, and Installing System Images

Installing the IPS-4240 and IPS-4255 System Image

You can install the IPS-4240 and IPS-4255 system image by using the ROMMON on the appliance to
TFTP the system image onto the compact flash device.
Note This procedure is for IPS-4240, but is also applicable to IPS-4255. The system image for IPS-4255 has
"4255" in the filename.
To install the IPS-4240 and IPS-4255 system image, follow these steps:
Download the IPS-4240 system image file (IPS-4240-K9-sys-1.1-a-5.0-1.img) to the tftp root directory
Step 1
of a TFTP server that is accessible from your IPS-4240.
For the procedure for locating software on Cisco.com, see
Note
Boot IPS-4240.
Step 2
The console display resembles the following:
Booting system, please wait...
CISCO SYSTEMS
Embedded BIOS Version 1.0(5)0 09/14/04 12:23:35.90
Low Memory: 631 KB
High Memory: 2048 MB
PCI Device Table.
Bus Dev Func VendID DevID Class
00
00
00
00
00
00
00
00
00
00
00
00
00
00
02
03
03
03
03
03
04
04
Evaluating BIOS Options ...
Launch BIOS Extension to setup ROMMON
Cisco Systems ROMMON Version (1.0(5)0) #1: Tue Sep 14 12:20:30 PDT 2004
78-16527-01
Make sure you can access the TFTP server location from the network connected to your
IPS-4240's Ethernet port.
00 00 8086 2578 Host Bridge
01 00 8086 2579 PCI-to-PCI Bridge
03 00 8086 257B PCI-to-PCI Bridge
1C 00 8086 25AE PCI-to-PCI Bridge
1D 00 8086 25A9 Serial Bus
1D 01 8086 25AA Serial Bus
1D 04 8086 25AB System
1D 05 8086 25AC IRQ Controller
1D 07 8086 25AD Serial Bus
1E 00 8086 244E PCI-to-PCI Bridge
1F 00 8086 25A1 ISA Bridge
1F 02 8086 25A3 IDE Controller
1F 03 8086 25A4 Serial Bus
1F 05 8086 25A6 Audio
01 00 8086 1075 Ethernet
01 00 177D 0003 Encrypt/Decrypt
02 00 8086 1079 Ethernet
02 01 8086 1079 Ethernet
03 00 8086 1079 Ethernet
03 01 8086 1079 Ethernet
02 00 8086 1209 Ethernet
03 00 8086 1209 Ethernet
Cisco Intrusion Prevention System Sensor CLI Configuration Guide for IPS 5.0
Obtaining Cisco IPS Software, page
Irq
11
10
9
11
5
5
11
9
9
9
9
9
11
5
Installing System Images
18-1.
17-15
