Configuring EtherChanneling
•
•
•
Verify the load balancing:
Step 10
cat6k# show etherchannel load-balance
EtherChannel Load-Balancing Configuration:
EtherChannel Load-Balancing Addresses Used Per-Protocol:
Non-IP: Source XOR Destination MAC address
IPv4: Source XOR Destination IP address
IPv6: Source XOR Destination IP address
MPLS: Label or IP
Set the VLANs to be captured to the EtherChannel:
Step 11
router(config)# intrusion-detection port-channel channel_number capture allowed-vlan
vlan_list
Step 12 Enable capture to the EtherChannel:
router(config)# intrusion-detection port-channel channel_number capture
Exit global configuration mode:
Step 13
router(config)# exit
To save the changes:
Step 14
router# write memory

Disabling EtherChanneling

To disable IDSM-2 EtherChanneling, follow these steps:
Step 1 Log in to the console.
Step 2 Enter global configuration mode:
router# configure terminal
To remove a single IDSM-2 from the EtherChannel:
Step 3
router(config)# no intrusion-detection module module_number data-port data_port_number
channel-group channel_number
Cisco Intrusion Prevention System Sensor CLI Configuration Guide for IPS 5.0
15-22
—Source IP address
src-ip
src-mac—Source MAC address
src-port—Source TCP/UDP port
The default is src-dst-ip., which means EtherChannel uses the combination of source and
destination IP addresses for its distribution method.
src-dst-ip
