Chapter 1
Hardware Installation
c.
If you put DS1N-14 cards in Slots 3 and 15 to form 1:N protection groups, do not wire Slots 3 and 15
for DS-1 electrical interface adapters.
Figure 1-28
attached on both sides of the shelf assembly to create DS-1 twisted-pair termination points.
Figure 1-28 A backplane with SMB EIA for DS-1 cables
1.11.2 AMP Champ Connector Installation
To install AMP Champ connector DS-1 cables, you must use 64-pin bundled cable connectors with a
64-pin male AMP Champ connector. You need an AMP Champ connector #552276-1 for the receptacle
side and #1-552496-1 (for cable diameter .475in.–.540in) or #2-552496-1 (for cable diameter
.540in.–.605in.) for the right-angle shell housing (or their functional equivalent). The corresponding
64-pin female AMP Champ connector on the AMP Champ EIA supports one receive and one transmit
for each DS-1 port for the corresponding card slot.
Because each DS1-14 card supports 14 DS-1 ports, only 56 pins (28 pairs) of the 64-pin connector are
used. Prepare one 56-wire cable for each DS-1 facility installed.
for the AMP Champ connectors on the ONS 15454 AMP Champ EIA. See the
section on page 1-20
Table 1-5
Signal/Wire
Tx Tip 1
white/blue
Tx Tip 2
white/orange
November 2001
Terminate the shield ground wire on the DS-1 cable to ground according to local site practice.
shows a ONS 15454 backplane with an SMB EIA with DS-1 electrical interface adapters
DS-1 Electrical Interface
Adapter or balun
for more information about the AMP Champ EIA.
Pin Assignments for AMP Champ Connectors (Shaded Area Corresponds to White/Orange
Binder Group)
Pin
Pin
1
33
2
34
Signal/Wire
Signal/Wire
Tx Ring 1
Rx Tip 1
blue/white
yellow/orange
Tx Ring 2
Rx Tip 2
orange/white
yellow/green
Cisco ONS 15454 Installation and Operations Guide
DS-1 Cable Installation
Table 1-5
shows the pin assignments
"AMP Champ EIA"
Pin
Pin
Signal/Wire
17
49
Rx Ring 1
orange/yellow
18
50
Rx Ring 2
green/yellow
1-41
