Workpiece status
Good
Rework
Scrap
Measured deviation with Cycle 440
X axis
Y axis
Z axis
Markers for cycles
Tool measurement with the BLUM laser
Reserved
Reserved
Reserved
Reserved
Reserved for internal use
Markers for cycles
Markers for cycles
Markers for cycles (machining patterns)
Number of the last active measuring cycle
Status of tool measurement with TT
Tool within tolerance
Tool is worn (LTOL/RTOL is exceeded)
Tool is broken (LBREAK/RBREAK is
exceeded)
HEIDENHAIN iTNC 530
Parameter value
Q180
Q181
Q182
Parameter value
Q185
Q186
Q187
Q188
Parameter value
Q190
Q191
Q192
Q193
Parameter value
Q195
Q196
Q197
Q198
Parameter value
Q199 = 0.0
Q199 = 1.0
Q199 = 2.0
