HEIDENHAIN ITNC 530 - 6-2010 DIN-ISO PROGRAMMING User Manual page 550

Setting Meaning
Domain Name Automatically procure DNS option:
Server (DNS) The TNC is to automatically procure the IP
address of the domain name server
Manually configure the DNS option:
Manually enter the IP addresses of the
servers and the domain name
Default Automatically procure default gateway
gateway option:
The TNC is to automatically procure the
default gateway
Manually configure the default gateway
option:
Manually enter the IP addresses of the default
gateway
U Apply the changes with the OK button, or discard them with the
Cancel button
U The Internet tab currently has no function.
Setting Meaning
Proxy Direct connection to Internet/NAT:
The control forwards Internet inquiries to the
default gateway and from there they must be
forwarded through network address
translation (e.g. if a direct connection to a
modem is available)
Use proxy:
Define the Address and Port of the Internet
router in your network, ask your network
administrator for the correct address and
port
Telemaintenance The machine manufacturer configures the
server for telemaintenance here. Changes
must always be made in agreement with your
machine tool builder.
550 MOD Functions
