Editing function
Go to beginning of next line
Add the number of lines that can be entered at
the end of the table
Copy the highlighted field (2nd soft-key row)
Insert the copied field (2nd soft-key row)

Selecting a pallet table

U Call the file manager in the Programming and Editing or Program
Run mode: Press the PGM MGT key.
U
To display all type .P files, press the soft keys SELECT TYPE and
SHOW .P.
U Select a pallet table with the arrow keys, or enter a new file name
to create a new table.
U Confirm your entry with the ENT key.
Leaving the pallet file
U Press the PGM MGT soft key to call the file manager.
U
To select a different type of file, press the SELECT TYPE soft key
and the soft key for the desired file type, for example SHOW.H.
U Select the desired file
420
Soft key
Programming: Pallet Editor
