HEIDENHAIN ITNC 530 - 6-2010 DIN-ISO PROGRAMMING User Manual page 162

Abbr. Inputs
TT:L-OFFS Radius measurement: tool offset in addition to MP6530 between
upper surface of stylus and lower surface of tool. Default: 0
Input range in mm: -99999.9999 to +99999.9999
Input range in inches: -3936.9999 to +3936.9999
LBREAK Permissible deviation from tool length L for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Input range in mm: 0 to 0.9999
Input range in inches: 0 to +0.03936
RBREAK Permissible deviation from tool radius R for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Input range in mm: 0 to 0.9999
Input range in inches: 0 to +0.03936
162
Dialog
Tool offset: length?
Breakage tolerance: length?
Breakage tolerance: radius?
Programming: Tools
