HEIDENHAIN ITNC 530 - 6-2010 DIN-ISO PROGRAMMING User Manual page 599

Software option 1
Rotary table machining
Coordinate transformation
Interpolation
Software option 2
3-D machining
Interpolation
Block processing time
DXF Converter software option
Extracting contour programs
and machining positions from
DXF data
Dynamic Collision Monitoring (DCM) software option
Collision monitoring in all
machine operating modes
Additional conversational language software option
Additional conversational
languages
HEIDENHAIN iTNC 530
Programming of cylindrical contours as if in two axes
Feed rate in distance per minute
Tilting the working plane
Circle in 3 axes with tilted working plane
Motion control with minimum jerk
3-D tool compensation through surface normal vectors
Using the electronic handwheel to change the angle of the swivel head during program
run without affecting the position of the tool point (TCPM = Tool Center Point
Management)
Keeping the tool normal to the contour
Tool radius compensation normal to the direction of traverse and the tool direction
Spline interpolation
Linear in 5 axes (subject to export permit)
0.5 ms
Format supported: AC1009 (AutoCAD R12)
For plain-language and smarT.NC
Simple and convenient specification of reference points
The machine manufacturer defines objects to be monitored
Fixture monitoring is also possible
Three warning levels in manual operation
Program interrupt during automatic operation
Includes monitoring of 5-axis movements
Program simulation before machining for possible collisions
Slovenian
Norwegian
Slovak
Latvian
Korean
Estonian
Turkish
Romanian
Lithuanian
599
