User functions
Actual position capture
Program verification graphics
Display modes
Programming graphics
Program Run graphics
Display modes
Machining time
Returning to the contour
Datum tables
Pallet tables
Touch probe cycles
Specifications
Components
Program memory
Input resolution and display
step
Input range
596
Actual positions can be transferred directly into the NC program
Graphic simulation before program run, even while another program is being run
Plan view / projection in 3 planes / 3-D view
Magnification of details
In the Programming and Editing mode, the contours of the NC blocks are drawn on
screen while they are being entered (2-D pencil-trace graphics), even while another
program is running
Graphic simulation of real-time machining in plan view / projection in 3 planes /
3-D view
Calculating the machining time in the Test Run mode of operation
Display of the current machining time in the Program Run modes
Mid-program startup in any block in the program, returning the tool to the calculated
nominal position to continue machining
Program interruption, contour departure and return
Multiple datum tables
Pallet tables (with as many entries as desired for the selection of pallets, NC programs
and datums) can be machined workpiece by workpiece or tool by tool
Calibrate touch probe
Compensation of workpiece misalignment, manual or automatic
Datum setting, manual or automatic
Automatic workpiece measurement
Cycles for automatic tool measurement
Cycles for automatic kinematics measurement
MC 6241 or MC 6222 main computer
CC 6106, 6108 or 6110 controller unit
Keyboard
15.1-inchor 19-inch TFT color flat-panel display with soft keys
At least 21 GB,
Up to 0.1 µm for linear axes
Up to 0.0001° for angular axes
Maximum 99 999.999 mm (3.937 inches) or 99 999.999°
