Data transfer from cutting data tables

If you output a file type .TAB or .CDT via an external data interface, the
TNC also transfers the structural definition of the table. The structural
definition begins with the line #STRUCTBEGIN and ends with the line
#STRUCTEND. The meanings of the individual code words are shown
in the table "Structure Command" . Behind #STRUCTEND the TNC
saves the actual content of the table.

Configuration file TNC.SYS

You must use the configuration file TNC.SYS if your cutting data tables
are not stored in the standard directory TNC:\. In TNC.SYS you must
then define the paths in which you have stored your cutting data
tables.
The TNC.SYS file must be stored in the root directory
TNC:\.
Entries in TNC.SYS Meaning
WMAT= Path for workpiece material table
TMAT= Path for cutting material table
PCDT= Path for cutting data tables
Example of TNC.SYS
WMAT=TNC:\CUTTAB\WMAT_GB.TAB
TMAT=TNC:\CUTTAB\TMAT_GB.TAB
PCDT=TNC:\CUTTAB\
HEIDENHAIN iTNC 530 379
