Coordinate transformation
Coordinate
Activate
transformation
Datum G54 X+20 Y+30
shift Z+10
Mirror image G28 X
Rotation G73 H+45
Scaling factor G72 F 0.8
Working plane G80 A+10 B+10
C+15
Working plane PLANE ...
Q-parameter definitions
D Function
00

Assignment

01 Addition
02 Subtraction
03 Multiplication
04 Division
05 Root
06 Sine
07 Cosine
08 Root sum of squares c = a
09 If equal, go to label number
10 If not equal, go to label number
11 If greater than, go to label number
12 If less than, go to label number
13 Angle from c sin a and c cos a
14 Error number
15 Print
19 Assignment PLC
Cancelation
G54 X0 Y0 Z0
G28
G73 H+0
G72 F1
G80
PLANE RESET
2 2
+b
