HEIDENHAIN ITNC 530 - 6-2010 DIN-ISO PROGRAMMING User Manual page 28

9.10 Preassigned Q Parameters ..... 288
Values from the PLC: Q100 to Q107 ..... 288
WMAT block: QS100 ..... 288
Active tool radius: Q108 ..... 288
Tool axis: Q109 ..... 289
Spindle status: Q110 ..... 289
Coolant on/off: Q111 ..... 289
Overlap factor: Q112 ..... 289
Unit of measurement for dimensions in the program: Q113 ..... 290
Tool length: Q114 ..... 290
Coordinates after probing during program run ..... 290
Deviation between actual value and nominal value during automatic tool measurement with the TT 130 ..... 291
Tilting the working plane with mathematical angles: rotary axis coordinates calculated by the TNC ..... 291
Measurement results from touch probe cycles (see also User's Manual for Touch Probe Cycles) ..... 292
9.11 Programming Examples ..... 294
