Global program settings 1 (GPS1 tab, software option)
The TNC only displays the tab if the function is active on
your machine.
Soft key Meaning
No direct Swapped axes
selection
possible
Superimposed datum shift
Superimposed mirroring
Global program settings 2 (GPS2 tab, software option)
The TNC only displays the tab if the function is active on
your machine.
Soft key Meaning
No direct Locked axes
selection
possible
Superimposed basic rotation
Superimposed rotation
Active feed rate factor
