1. Turn off and unplug the system and any external options.
2. Remove the system unit side panel (see "Removing the Side Panel" in Section 3).
Locate the jumper bank on the system board (see Figure B-1).
3.
Move the jumper to the position shown in the following figure.
4.
5. Turn on power and allow the system to boot.
6. Turn off power.
Move the jumper back to the default position shown in the following figure to
7.
restore normal operation.
Replace the system cover and turn the power back on.
8.

Setup Program Jumper

Use the following procedure to disable access to the Setup program in the BIOS.
1. Turn off and unplug the system and any external options.
2. Remove the system unit side panel (see "Removing the Side Panel" in Section 3).
Locate the jumper bank on the system board (see Figure B-1).
3.
UP
A B G H
C D E F I
DOWN
Figure B-6 Clear CMOS Setting
UP
A B C D E G H I
F
DOWN
Figure B-7 Normal CMOS Setting
System Board Settings
Reset CMOS settings
to default CMOS RAM
values.
Normal mode
(Default)
B-5
