Scsi Board - NEC PowerMate Pro150 Series Service Manual

n
Programmable effects engine for reverb, chorus, vibrato, tremolo and Qsound
surround sound.
n
1 MB ROM for MIDI and Roland Sound Canvas compatibility
n
512K RAM onboard for SoundFont sample sound support
n
20-voice SB compatible music synthesizer
n
MPU-401 UART and Sound Blaster MIDI interface
n
Sound Blaster 16, General MIDI, MPC2 and Windows 3.1 compatible.
If CMOS is cleared, the sound board settings stored in the BIOS will not be restored with
the defaults. Use an ISA Configuration Utility (ICU) to restore the sound board settings.
The NEC defaults are as follows.
n
I/O RANGE:
n
I/O RANGE:
n
I/O RANGE:
n
I/O RANGE:
n
IRQ:
n
DMA
n
DMA

SCSI BOARD

Systems come with an Adaptec 2940W SCSI adapter board installed in an ISA expansion
slot. The SCSI adapter board brings the highest performance SCSI I/O technology to the
PCI local-bus transferring data up to 133 MB/second. The SCSI adapter board is
compatible with all major operating system, SCSI-2 and SCSI-3 peripherals, as well as
industry-standard application software.
The BIOS-resident SCSISelect configuration utility eliminates the need to handle jumpers
or terminators while adding peripherals. All configuration and terminator settings are
controlled via the keyboard. The SCSI adapter board feature the following:
n
Utilizes the PCI local-bus
n
Bus master DMA interface protocol
n
32-bit bus width
n
Up to 133 MB/second data transfer rate
n
Fast and wide 20 MB/second SCSI synchronous data rate
n
6 MB/second SCSI asynchronous data rate
0220-0233
0330-0331
0388-038B
0200-0207
05
01
05
Technical Information 1-15
