B-4 System Board Settings
4. Move the jumper to the position shown in the following figure.
5. Turn on power and allow the system to boot.
Turn off power.
6.
Move the jumper to the position shown below to restore normal operation.
7.
8. Replace the system cover and turn the power back on.
9. Run Setup to set a new password (see "The Security Menu" in Section 2).

CMOS RAM Jumper

Use the following procedure to clear the CMOS on the system board. This procedure
should be done after the system BIOS is updated.
UP
A B C D E F G H
DOWN
Figure B-4 Clear Password Setting
UP
A B G H
C D E F
DOWN
Figure B-5 Normal Password Setting
CAUTION: Do not use this procedure if
running Windows 95. Clearing CMOS RAM
after a BIOS upgrade erases the Plug and Play
data in the CMOS RAM. To clear CMOS RAM
on a Windows 95 system, press the
anywhere in the Setup program. This resets all
Setup options to their defaults. See Chapter 2 for
information on the Setup program.
Clear password
I
Normal mode
(Default)
I
key from
F5
