1-20 Technical Information

SPECIFICATIONS

System specifications are included in Table 1-8.
Item
Dimensions and
Weight
Keyboard Dimensions and
Weight:
Device Slots
Expansion Slots
Peripheral Interface
Front Panel
Table 1-8 Specifications
Specification
Width: 8.3 inches (21 cm)
Depth: 17 inches (42.5 cm)
Height: 15.5 inches (39 cm)
Weight: 21.4 lb. (9.79 kg) (dependent upon options)
Width: 19.0 inches (48.3 cm)
Depth: 8.4 inches (21.3 cm)
Height: 1.6 inches (4.1 cm)
Weight: 3.5 to 4.0 lb. (1.6 to 1.8 kg)
Three 1.6-inch high, 5 1/4-inch, front accessible slots
One 1.6-inch high, 3 1/2-inch front access slot
Two 1-inch high, 3 1/2-inch internal slots
Five slots:
three 32-bit PCI slots
two 8-/16-bit ISA slots
one shared ISA or PCI slot
System Board, rear panel
PS/2-style keyboard connector, rear panel
PS/2-style mouse connector, rear panel
Two RS-232C serial ports,
Parallel printer port
Video Board, rear panel
VGA connector
Video feature connector
Sound Board, rear panel
Line in jack
Line out Jack
Microphone jack
MIDI connector
SCSI Board, rear panel
External SCSI connector
Network Board, rear panel (network ready systems)
10/100 RJ-45 Ethernet connector
Power button
Power indicator lamp
Hard disk drive busy indicator lamp
Reset button
infrared IrDA transceiver
