A.4 Connectors
A.4.1 LAN connector (switch)
RJ45 LAN
A.4.2 WAN Base-T connector
RJ45 WAN
A.4.3 WAN SFP connector
SFP
A.4.4 WWAN connector
Devices equipped with this interface have up to four SMA female connectors installed.
RS1800 series
RJ45 PIN
1
2
3
4
5
6
7
8
RJ45 PIN
1
2
3
4
5
6
7
8
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
Standard SFP connector
Technical Information
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
