In installations where only one SIM card is required, we recommend that it is installed in the main SK1 tray.
Warning
Never install the SIM cards when the device is switched on.
Always disconnect the device from the main power supply before installing the SIM cards.
Always disconnect the device before removing the casing to access the trays.
When inserting the SIM cards, please protect yourself against electrostatic discharges (ESD).
Do not touch the SIM card connectors.
To access the SIM tray you need to open the upper casing of the device. To do this, undo the four screws on the top
panel of the Regesta Lite AU:
Screws on the upper casing
Fig. 14:

3.6.1 Identifying the SIM trays

Once you have removed the upper casing, you will be able to see the different elements illustrated below.
The Regesta Lite AUincorporates 2 SIM cards, which allow you to execute some special configurations. One ex-
ample is installing two SIM cards and using one as backup to the other. To carry out this type of configuration, you
must assign a tray to each SIM (since they require different configuration parameters).
The SIM trays are identified as SK1 and SK2 i.e. socket 1 and socket 2.
