2 Product Overview
Ethernet WAN in-
WAN
terface (RJ45)
Ethernet WAN in-
SFP
terface (SFP)
Multi standard seri-
S1
al interface 1
Multi standard seri-
S2
al interface 2
Note: The behavior of certain LEDs may vary based on the device's configuration.
2.4.2 Connector panel
The connector panel is protected by a casing that needs to be removed in order to access it. Please refer to
ing/Installing the connector protector
casing.
The following figure shows the panel that contains all the Regesta Smart PRO router connectors.
10
lished connection.
Green
Ethernet connection (link) established:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off
The Ethernet WAN is currently disabled or there is no estab-
lished connection.
Green
Ethernet connection (link) established:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off
SFP is not used.
Green
Ethernet SFP connection (link) is established
Off
Serial port 1 is disabled or not initialized.
Green
Port is in active state, shows interface activity:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off
Serial port 2 is disabled or not initialized.
Green
Port is in active state, shows interface activity:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
