SKILLRUN
Technical Service Guide - Rev. 6.0
Necessary components:
The following additional components are required to install the tread belt:
Support for the equipment in a
To facilitate the lifting of the tread belt can also be ordered the following components:
Number of technicians required:
• 2: if equipped with the accessory that blocks the equipment, when in a vertical position.
• 3: if not equipped with the accessory that blocks the equipment, when in a vertical position. The
additional technician must keep the equipment stable when it is in a vertical position.
Required space: 3-4 m
PROCEDURE
1. Turn off the equipment. Disconnect the power supply cable. ("8.3 Procedure to follow be-
fore disassembling the equipment").
2. Remove the front and rear side guard, on the right and left side of the equipment. ("8.10.1
Disassembling the rear side guard"; "8.10.2 Disassembling the front side guard").
3. Remove the front and rear footrest guard, on the right and left side of the equipment. ("8.11
Disassembling the footrest guard").
4. Remove the front guard. ("8.10.3 Disassembling the front guard").
Uncontrolled copy if printed
COMPONENT
Tread belt
ISOFLEX Topas L32 (45g)
COMPONENT
Machine lifting foot
M16 nut
lateral position
M10 L75 screw
COMPONENT
Handle
Safety bushings
.
2
Q.TY
1
1
Q.TY
2
4
1
1
Q.TY
2
8
