Technogym SKILLRUN UNITY 7000 Technical Service Manual page 218

TENSIONING THE TOOTHED BELT 14 mm - 16 mm:
- if the belt is replaced with a new one, tension the belt to the frequency: 200 ± 5 Hz.
- if the belt is loosened / removed and then the same one is reassembled: tension the belt to the
frequency: 180 ± 5 Hz.
TENSIONING THE POLI-V BELT
- if the belt is replaced with a new one, tension the belt to the frequency: 220 ± 5 Hz.
- if the belt is loosened / removed and then the same one is reassembled: tension the belt to the
frequency: 190 ± 5 Hz.
Pag. 218
Figure 131 - poly-V belt
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed
SKILLRUN
