SKILLRUN
Technical Service Guide - Rev. 6.0
[1]: Patch connector N°6:
Figure 75- SkillRun TX 500
Figure 76- SkillRun Unity 5000- SkillRun Unity 7000
[2]: For details, see "6.1.1 REPLACING the display"
[3]: For details, see "6.1.2 replacing the drive".
[*]: For details, see "6.15 EQUIPMENT TESTING AFTER THE INTERVENTION OF TECHNICAL
Uncontrolled copy if printed
Pag. 137
