[*]: For details, see "6.15 EQUIPMENT TESTING AFTER THE INTERVENTION OF TECHNICAL
SERVICE".
[1]: For details see "6.5 procedure for restoring the low kit factory settings"
[2]: Check parameter P05: In the service menu (2501), access the LOW KIT section. Enter '5' and
read the value. Correct value ~ 400.
[3]: For details, see "6.1.2 replacing the drive".
[4]: Encoder operational check:
▪ Access the Service menu 2501;
▪ Access the Troubleshootings menu;
▪ Press START and check the speed (Km/h);
▪ Check that the frequency values of the DRIVE Output Frequency parameter (P36) are
around:
Speed
5 km/h
10 km/h
Pag. 144
DRIVE Output Frequency
[Hz]
~ 300 Hz
~ 600 Hz
Figure 85
Technical Service Guide - Rev. 6.0
Notes
If the test is carried out without
anyone walking/running on the
tread belt, the precision is around
1%.
If the test is carried out with a per-
son walking/running on the tread
belt, the precision is around 5%,
due to greater fluctuation.
