front pin bolt any further. Turn both the right and left bolts on the front roller to maintain the par-
allelism.
ATTENTION: maintain the parallelism of the rollers. This is important as regards the position of
the tread belt on the equipment. Turn one half turn at a time, both on the right and on the left side
of the roller.
4. Check that the adjustable bearings are in contact:
- loosen the central bearing;
- check and if necessary adjust the rear bearing to bring it into contact with the belt. Tighten.
- Let the central being fall onto the belt and tighten.
REAR PART
ADJUSTABLE
BEARING
5. Bring the SKILLRUN to a gradient of -3%. Increase the speed from 0 Km/h to 25 Km/h. Check
that the tread belt is centred: the distance between the frame and the tread belt must not be less
than 8 ± 3mm.
Pag. 124
ADJUSTABLE
BEARING
Figure 70
Technical Service Guide - Rev. 6.0
FRONT PART
FIXED
BEARING
