IO unit information and input / output data can be checked in the IO Detail window.
The diagnostic error type is represented by different background colours. The meaning of a background
colour can be checked by clicking [>>].
- Background colour
Background
Display
colour
Open
Short
Count
Over
* I/O details vary depending on the unit.
Detection of unconnected load
* Disabled in initial state. Enable the function from the I/O Configurator (Web version).
Short circuit detection
Contact frequency upper limit detection
* Disabled in initial state. Enable the function from the I/O Configurator (Web version).
-78-
Description
No.EX##-OMV0017-G
