Pairing

3.5
Pairing is required for communication between a Base and Remote.
A Base is paired with a Remote after they are switched to pairing mode.
Pairing and registration between a Base and Remote enables wireless communication.
 Operational flow during pairing
Switch the Remote to pairing mode
* The EXW1-RD# is set to pairing mode by factory default.
Switch the Base to pairing mode
* The Base can be switched to pairing mode using the specified protocol.
Pair and register the Base and Remote
Switch the Base to normal mode
* Remotes are switched to normal mode automatically.
•After changing the operation mode for pairing, the mode is changed by clicking the [Reset]
button or re-supplying power so that the mode will be changed to the Remote registration or
listing for connection.
•If the FCS function is to be used, please perform the FCS setting prior to pairing. After pairing
the advertising channels are fixed which limits the channels available for FCS setting.
•Ensure the power supply for both the base and remote is on when they are paired
•Exchange of I/O data is not possible during pairing
Do no chage the pairing mode during the operation.
•Module unit size of the remote is transferred to the base unit during the paring procedure.
When this size is changed after the pairing, please re-confifure the system.
Any parameter changes are enabled after the product is powered on or by pressing the "Reset
module" button.
