SMC Networks EXW1-BENAC1 Operation Manual page 33

Ethernet setting items (example using manifold-type wireless unit EX600-WEN)
Parameter name
MAC address
IP address type
IP address
Auto MDI/MDI-X
Duplex
Speed
- "Ethernet setting" is only displayed for a Base unit that supports EtherNet/IP.
● CC-Link setting
Make the CC-Link settings when using a Base unit that supports CC-Link.
The parameters below can be set (refer to "5.3 Properties tab").
CC-Link setting items (example using compact wireless unit EXW1-BMJA#)
Parameter name
Operating mode
Speed
Number of slave stations
- "CC-Link Setting" is only displayed for a Base unit that supports CC-Link.
-
Manual / DHCP / Remote Control
Enter value
Auto / MDI / MDIX
Full Duplex / Half Duplex
Auto / 100 Mbps / 10 Mbps
Set value
1 to 8
156 kbps / 625 kbps / 2.5 Mbps / 5 Mbps / 10 Mbps
1 to 64 stations
Set value
2
156 kbps
No value
-32-
Initial value
-
Manual
192.168.0.1
Auto
Full Duplex
Auto
Initial value
No.EX##-OMV0017-G
