Term
O Occupied points for
the module input /
output
P
Pairing
PID
PLC
R
Refresh button
Remote Control
Reset button
S
Short circuit detection
Short circuit
protection
W
Wireless Base
Wireless channel
Wireless Remote
Wireless unit
Number of I/O points that can be controlled by a module.
Registration of the PID (Product ID) of the Wireless Remote unit to be connected to the
Wireless Base unit. Registration occurs at the initial setting, then the wireless system
will activate.
Abbreviation of Product ID. A 32-bit numeric string allocated to identify the wireless unit
(Base / Remote).
Abbreviation of Programmable Logic Controller. A digital computer used for automation
of electromechanical processes.
Button to display the latest configuration of the wireless units, set by the I/O
Configurator (NFC version).
The mode to respond to the commands of BOOTP / DHCP Server provided by
Rockwell Automation. Gateway address and subnet mask can be set to any value.
Button to update the wireless units with the latest configuration set by the I/O
Configurator (NFC version). Restarting the controller will also activate the setting.
Diagnostic function which detects generation of an overcurrent due to a short circuit
between the output and the positive power supply line or the ground line.
Function which avoids damage to the internal circuit when overcurrent is generated
due to short circuit between the output and the positive power line or the ground line.
A unit which establishes wireless communication of input or output data to the Wireless
Remote. It is connected to a PLC to establish communication of input or output data.
Identification number of the Wireless Remote unit connected to the Wireless Base unit.
A unit which establishes wireless communication of input or output data to a Wireless
Base.
A unit which establishes wireless communication. This is a generic name for the
Wireless Base and Remote units.
-143-
Definition
No.EX##-OMV0017-G
