SMC Networks EXW1-BENAC1 Operation Manual page 31

Remote unit setting items (example using compact wireless unit EXW1-RDXNE4## / EXW1-RDYNE4## /
EXW1-RDM#E3##)
Parameter name
Input size*
Output size (includes valves)*
Wireless signal
Power Supply Voltage Monitor (Control/Input)
Power Supply Voltage Monitor (Output)
Output action when upper communication is
disconnected.
Output action when wireless communication is
disconnected.
* Although the number of occupied inputs / outputs of the EXW1-RDM# is fixed at 16 (16 bits), only the lower 8 bits are
available.
Remote unit setting items (example using manifold-type wireless unit EX600-WSV#)
Parameter name
HOLD/CLR (unit)
Input size
Output size (includes valves)
in which includes a valve density of
Wireless signal
AD refresh time (sec)
Unit address order
Set value
16 points (16 bits)
16 points (16 bits)
Active / Idle
Enable / Disable
Enable / Disable
Clear / Hold
Clear / Hold
Set value
Clear / Hold / Software Control
0 to 128 points (0 to 16 bytes)
0 to 128 points (0 to 16 bytes)
0 to 32 points (0 to 4 bytes)
Active / Idle
0.1 / 0.2 / 0.5 / 1 / 2 / 5 / 10 / 30 / 60 s
Mode 1 / Mode 2
-30-
Initial value
16 points (16 bits)
16 points (16 bits)
Active
Enable
Disable
Clear
EXW1-RDYNE4#:
Clear
EXW1-RDM#E3#:
Hold
Initial value
Clear
128 points/16 byte
128 points/16 byte
32 points/4 byte
Active
1 s
Mode 1
