Detailed Input / output information

4.3
The IO Detail window will open by double-clicking the line of an address of the I/O unit which is connected to
the wireless unit.
￥
￥
Double-click
The diagnostic error type is represented by different background colours. The meaning of a background
colour can be checked by clicking [>>].
I/O details vary depending on the unit. Refer to "5.2.3 IO details" for further details.
