- The compact Wireless Base (EXW1-BENAC1)
Parameter name
MAC address -
Manual / DHCP /
IP address type
Remote Control
0.0.0.1-
IP address
255.255.255.255
0.0.0.0-
Subnet Mask
255.255.255.255
0.0.0.0-
Default Gateway
255.255.255.255
Auto MDI/MDI-X Auto / MDIX / MDI
Full Duplex /
Duplex
Half Duplex
Communication Auto / 100 Mbps / 10
speed Mbps
*1 Function supported with firmware ver. 1.1.0 and later. The firmware version is displayed in the Information tab (refer to
"5.1 Information tab").
*2 Enable DHCP: Information including the IP address can be obtained from BOOTP / DHCP Server.
If power is supplied again in this state, information including the IP address is obtained again.
Disable DHCP: IP address etc. cannot be obtained from BOOTP / DHCP Server.
Previous settings can be held if power is supplied under this condition.
Set value Initial value
-
Manual
192.168.0.1
255.255.255.0
0.0.0.0
Auto
Full Duplex
Auto
MAC address of the product is displayed.
Select the IP address setting mode. Select the mode
suitable for your network environment.
Manual: The IP address is set by inputting it directly.
DHCP: The IP address is set automatically via the DHCP
server. The IP address obtained will be lost when
the power supply is cut.
Remote Control * 1 : The mode to respond to the Enable
DHCP and Disable DHCP commands *
with BOOTP / DHCP Server provided by Rockwell
Automation.
Set the IP address (The IP address is valid only when
"Manual" mode is selected).
Set the Subnet Mask (The IP address is valid only when
"Manual" mode is selected).
Set the Default Gateway (The IP address is valid only
when "Manual" mode is selected).
Select either straight cable or crossed cable. Select the
setting suitable for your environment.
Set to Full or Half Duplex. Select the setting suitable for
your environment. When the communication speed is set
to [Auto], it is set automatically regardless of the Duplex
setting.
Set the communication speed. Select the setting suitable
for your environment.
