SMC Networks EXW1-BENAC1 Operation Manual page 125

- Compact Wireless Remote unit (EXW1-RDYNE4##) setting parameters
Classificat
Parameter name
ion
a) Input size
b) Output size
Wireless
c)
signal
Power Supply
Voltage
d) Monitor
(Control /
Input)
Power Supply
Remote
Voltage
e)
setting
Monitor
(Output)
Output action
when upper
f) communicatio
n is
disconnected.
Output action
when wireless
g)
community is
disconnected.
Pairing
a) Pairing
setting
Brown-out
a) Detection for
US1
Brown-out
b) Detection for
US2
Output State
Parameter
Fieldbus
Tab
c) FaultIdle
Remote
Output State
for RF
d) Timeout
Set value
0 points / 0 byte 0 points / 0 byte
16 points / 2 byte 16 points / 2 byte
Active / Idle Active
Enable / Disable Enable
Enable / Disable Disable
Clear / Hold Clear
Clear / Hold Clear
Normal/pairing modes Normal mode
Enable/Disable Enable
Enable/Disable Disable
Clear/Hold
Clear
/Individual
Clear/Hold
Hold
/Individual
Setting
Initial value when power
is off
Fixed
Fixed
Available
Available
Available
Available
Available
Available
Not
available
Not
available
Not
available
Not
available
-124-
Note
If set to "Idle", the wireless
communication is disconnected.
Specify an output action for when the
fieldbus communication is
disconnected.
Specify an output action for when the
wireless communication is
disconnected.
Normal mode:
Wireless Remote cannot be
registered.
(Communication with the registered
Remote will be established).
Pairing mode:
Wireless Remote can be registered.
Generated error when power supply
voltage (US1) goes under approx.
19 V.
Generated error when power supply
voltage (US2) goes under approx.
19 V.
Only settable in protocol V.2.0.
In the case of protocol V.1.0, the value
on "Remote setting > Output action
when upper communication is
disconnected" is avalabe .
Only settable in protocol V.2.0.
In the case of protocol V.1.0, the value
on "Remote setting > Output action
when wireless community is
disconnected"is avalabe.
