System compatibility

1.4
Mixed use with EX600-W Series
Although it is possible to use with EX600-W series, the operating conditions must comply with the
specifications of the existing wireless system. Note that the following functions may be restricted:
•Communication distance
The maximum communication distance will vary depending upon the system configuration. Please see
the details in the table on the next page.
•Protocol
This refers to the wireless communication version. For more details, check the system settings of the
Base.
•Frequency channel select function (F.C.S.)
The frequency channel to use can be selected using this function.
* The number of selectable frequency channels varies depending on the country of use.
For more details, check the product number.
Number of selectable frequency channels
Min. 5 channels, Max. 79 channels
Min. 15 channels, Max. 79 channels
* If no channel is selected, communication is established on 79 channels by default.
* For the latest information, refer to the catalog on the website below.
URL https://www.smcworld.com
The figure below shows an example where only the frequency channels that do not clash with two wireless
LAN channels are used for wireless communication.
No communication
Frequency channel
Communication is established only on frequency channels selected using F.C.S.
•WEB function (supported only by EX600-WEN/WPN)
Various product settings and communication statuses can be checked by accessing EX600-WEN/WPN
from a PC.
•Radio output level setting function
This function reduces the radio output level to reduce the impact of SMC radio equipment on other radio
equipment.
This setting is reflected in the base and in the remote of the paired wireless adapter connection.
See the base system settings for details.
•Wireless communication timeout period
When wireless communication (including retries) is not successful due to obstacles or other factors, this
function (setting) determines that communication has failed and disconnects and reconnects wireless
communication after a set period of time.
Certified countries except for the U.S., Canada,
South Korea, Brazil, Taiwan, Argentina, and Mexico.
Certified countries including the U.S., Canada,
South Korea, Brazil, Taiwan, Argentina, and Mexico.
No communication
Frequency channel
1ch to 79ch
-7-
Applicable country
No.EX##-OMV0017-G
