- Base unit parameters
Parameter
Set value
name
CLEAR
HOLD/CLR
HOLD
(unit)
Software Control
0 to 128 points (0
Input size
to 16 bytes)
Output size
0 to 128 points (0
(includes
to 16 bytes)
valves)
in which
includes a
0 to 32 points
valve density
(0 to 4 bytes)
of
Wireless
Active
signal
Idle
Unit address
Mode 1
order
Mode 2
- Base unit setting buttons
No.
Name
1
Save all
2
Read factory data
Product
3
initialization
Initial value
CLEAR
128 points /
16 byte
128 points /
16 byte
32 points /
4 byte
Active
Mode 1
Changed settings are stored in the equipment. Perform a Reset to reflect the setting.
Button to read the default value of the window being displayed. Refer to "3.9 Reading of
factory data" for details on using this function.
Initialize (reset) the unit to the default condition. Refer to "3.10 Initialization of the
product" for details on using this function.
Description
Define all settings that are in output operation status when
fieldbus communication is disconnected.
CLEAR: Clear the output.
HOLD: Fix the output at the current value.
Software Control: CLEAR, HOLD or SET for individual
points can be set using bit data.
* Software Control is selectable only for manifold-type units.
Refer to "3.7 Software Control" for setting details.
Set the number of inputs which can be controlled by the
Wireless Base unit.
Setting range: 0 to 128 points (0 to 16 bytes). Increase or
decrease by 16 points.
Set the number of outputs which can be controlled by the
Wireless Base unit.
Setting range: 0 to 128 points (0 to 16 bytes). Increase or
decrease by 16 points.
The module output points include the number of points of
the valve manifold output.
Set the number of outputs to be allocated to the valve
manifold output from the number of points set in the module
output size.
As the valve manifold output points are included in the
module output points, the number of effective points are
limited to within the setting range of the module output
points.
Setting range: 0 to 32 points (0 to 4 bytes). Increase or
decrease by 8 points.
Define the operation status of wireless communication. *
Wireless communication is updated in real time. Turning the
power supply off and on again or a Reset is not necessary.
Active: Wireless communication is available.
Idle: Disconnect the wireless communication.
Define the address assignment direction of the EX600 I/O
units connected to the Wireless Base unit.
The address assignment direction is changed by mode
1/mode 2. Be careful about the I/O mapping.
(Refer to the I/O Mapping Order of Wireless Base / Remote
Module of the Operation Manual (page 50) for details)
Mode 1: Assigned to the right from the end plate.
Mode 2: Assigned to the left from the wireless unit.
