3. Setting of the wireless unit system

Installation of the SMC wireless system (Base and Remote) so that it can be controlled by an upper level
controller is described here. Grayed out items do not use the I/O Configurator. Refer to the operation manual
for each product.
3.1

Flow of setting operation

To use a wireless unit system, use the I/O Configurator (NFC version) and an NFC reader / writer to make
settings on the wireless units (Base and Remotes).
Make the following settings in Administrator mode in the I/O Configurator (NFC version).
(1) Download and install the I/O Configurator (NFC version)
* This manual can be used with ver. 2.12.0 of the I/O Configurator (NFC version).
(1) Parameter settings of "Remotes" (optional)
* Make settings in Administrator mode in the I/O Configurator.
(2) Set the number of occupied I/O points for the module and each
parameter of the "Base"
* Different from the I/O points of the whole system.
* Make settings in Administrator mode in the I/O Configurator.
(3) "Base" system settings
* Make settings in Administrator mode in the I/O Configurator.
(4) Register the Remote to the Base (pairing)
* The Base and Remote need to be powered.
* Make settings in Administrator mode in the I/O Configurator.
(5) Assemble the I/O unit (Wireless Base)
(6) Installation and wiring
(7) Fieldbus setting
Note) Refer to the operation manual of the PLC manufacturer for connection to PLC and I/O Configurator.
Procedure 1 Preparation (PC application)
Procedure 2 Setting/installation of the wireless unit
Procedure 3 Connection to PLC
* Refer to the operation manual of the Base for details.
