SMC Networks EXW1-BENAC1 Operation Manual page 105

(5)-f FCS Setting (Frequency Channel Select）
The frequency channel can be selected using this function. This function is only supported by protocol
V.2.0. Specify protocol V.2.0 in [System setting].
FCS Setting cannot be used if communication with subordinate Remotes uses a mixture of protocols.
Ensure that only Remote units that support protocol V.2.0 are registered to the Base with which FCS
Setting is to be used.
* The number of selectable frequency channels varies depending on the country in use. Refer to the
operation manual of the Base for details.
* If no channel is selected, communication is established on ch 79 by default.
Follow the steps below to configure the function on the Remote unit registration screen on the Properties
tab.
(1) Set [Pairing] to [Normal mode].
Refer to "3.5 Pairing" for details on pairing.
(2) Click [FCS Setting].
￥
(1)
(2)
-104-
￥
No.EX##-OMV0017-G
