SMC Networks EXW1-BENAC1 Operation Manual page 136

- Compact Wireless Remote unit (EXW1-RLBPA7C(ClassB)) setting parameters (continued)
Classificat Parameter
ion name
Pd Byte
a)
swap
L+ Power
b)
ON
Port Input
c)
IO-Link Size
Port Output
d)
IO-Link Size
*1
e) PortMode
Validation&
f)
Backup *1
Parameter
Tab
IO-Link
P#
PortCycle
g) Time
*1
*1
h) VendorID
*1
i) DeviceID
IO-Link
State for
j)
Fieldbus
Fault
IO-Link
State for
k)
Fieldbus
Idle
IO-Link
l) State for RF
Timeout
*1
Reconnect IO-Link devices when parameters are changed. Do no chage the pairing mode during the operation.
Set value
Direct / Swap 16 bit / Swap 32 bit /
Swap all
Power ON / 1 : Power OFF
Protocol setting : V.2.0
0 to 32 bytes (by 2 bytes)
Protocol setting : V.1.0
0 to 14 bytes (by 2 bytes)
Protocol setting : V.2.0
0 to 32 bytes (by 2 bytes)
Protocol setting : V.1.0
0 to 14 bytes (by 2 bytes)
Deactivated
/IOL_Manual
/IOL_Autostart
/DI C/Q
/DO C/Q
No Device Check
/Type compatible Device V1.0
/Type compatible Device V1.1
/Type compatible Device V1.1,
Backup+Restore
/Type compatible Device V1.1,
Restore
0 to 191
0 to 65535
0 to 16777215
Clear(Data Valid)/ Clear(Data
Invalid)/Hold
Clear(Data Valid)/ Clear(Data
Invalid)/Hold
Clear(Data Valid)/ Clear(Data
Invalid)/Hold
Setting
when
Initial value
power is
off
Not
Direct
available
Not
Power ON
available
P1,P2: 16byte
Not
P1: 8byte available
P2: 6byte
P1,P2: 16byte
Not
P1: 8byte
available
P2: 6byte
P1,P2:IOL_Auto
Not
start
available
Not
No Device Check
available
Not
0
available
Not
0
available
Not
0
available
Clear/ PD Out Not
invalid available
Clear/ PD Out Not
invalid available
Clear/ PD Out Not
invalid available
-135-
Note
Swap the byte order of the process
data, which is exchanged between
fieldbus communication and IO-Link
master.
For Control L+.
0:As fast as possible
1 to 3:0.4ms
4 to 63:0.4 to 6.3 ms (by 0.1 ms)
64 to 127:6.4 to 31.6 ms(by 0.4 ms)
128 to 191:32 to 132.8 ms(by 1.6
ms)
Setting for vendor ID which is
compared when the IO-Link device
comparison function is valid.
Setting for device ID which is
compared when the IO-Link device
comparison function is valid.
*Clear/ PD Out valid:
All outputs are turned OFF and
process data outputs remain valid.
*Clear/ PD Out invalid:
All outputs are turned OFF and
Process data outputs become
invalid.
*Hold:
Process data outputs remain valid.
IO-link master holds the last
process data it received.
No.EX##-OMV0017-G
