- Compact Wireless Remote unit (EXW1-RDM#E3##) setting parameters (continured)
Classificati
Parameter name
on
Short Circuit
a)
Detection(Output)
b) Restart After ShortCircuit Auto/Manual
Ch 7-0:
c) ON/OFF Counter Limit
Detection
Ch 7-0:
d)
Open Circuit Detection
Ch 7-0:
e) Hold State for Fieldbus
Fault
Ch 7-0:
f) Output State for Fieldbus
Parameter
Fault
Tab
DITIGAL
OUTPUT
Ch 7-0:
g) Hold State for Fieldbus
Idel
Ch 7-0:
h) Output State for Fieldbus
Idel
Ch 7-0:
i) Hold State for RF
TimeOut
Ch 7-0:
j) Output State for RF
TimeOut
Ch# Counter Limit Value
k)
(1-65000k)
Set value Initial value
Enable/Disable Enable
Manual
0x00-0xFF 0x00
0x00-0xFF 0x00
0x00-0xFF 0xFF
0x00-0xFF 0x00
0x00-0xFF 0xFF
0x00-0xFF 0x00
0x00-0xFF 0x00
0x00-0xFF 0x00
1-65000 65000
-129-
Setting when
power is off
Not available
Not available
1: Generates an error.
0; Does not generate an error.
Bit0:Channel 0
Not available
:
Bit7:Channel 7
1: Generates an error.
0; Does not generate an error.
Bit0:Channel 0
Not available
:
Bit7:Channel 7
0: Hold the output
1: Depend on output state
Bit0:Channel 0
Not available
:
Bit7:Channel 7
0: Turn off the output
1: Turn on the output forcefully
Bit0:Channel 0
Not available
:
Bit7:Channel 7
0: Hold the output
1: Depend on output state
Bit0:Channel 0
Not available
:
Bit7:Channel 7
0: Turn off the output
1: Turn on the output forcefully
Bit0:Channel 0
Not available
:
Bit7:Channel 7
0: Hold the output
1: Depend on output state
Bit0:Channel 0
Not available
:
Bit7:Channel 7
0: Turn off the output
1: Turn on the output forcefully
Bit0:Channel 0
Not available
:
Bit7:Channel 7
Times for setting is set value x1000
Not available
times
Note
