Parameter tab

5.6
Parameter tab consists of 2 areas, "System configuration" and "Parameter". The parameters of unit can be
changed as required.
(2)
- Wireless tab display
No.
(1) Part No.
(2) Unit No.
(3) Setting / Diagnostics Tab
(4) Item
(5) Status
(6) Value
(7) Save
(8) Read
(9) Clear wireless log
(3)
(1)
Display
(5)
(4)
Click to display remote unit parameters in the parameter
area.
Click to display the parameters of the selected IO unit in the
parameter frame.
Selects the displayed tab, "Setting parameter" or
"Diagnostics parameter".
The parameter name is displayed.
Displye the current status of the parameter.
Enter the parameters to change.
Saves the entered parameters in "Value" to the product.
The setting is available only in administrator mode.
*Only settable in Administrator mode.
Reload the parameters of the tabs displayed.
Clear all wireless log data.
-113-
(8)
(6)
(7)
￥
Description
