Monitor mode and Administrator mode

2.4
The user can select from Monitor mode and Administrator mode using the I/O Configurator (NFC version)
depending on the functions that are to be used.
- Monitor mode
Wireless unit information or I/O map and parameter settings can be read. Parameters cannot be set.
The Forced output function cannot be used.
- Administrator mode
All functions can be used.
Login to administrator mode
A password is necessary to log in to Administrator mode.
Any password can be set. To prevent unauthorized use, it is advisable to change the default password when
the I/O Configurator is first used.
(1) Select the [Administrator mode] radio button.
(2) Type a password while holding the NFC reader / writer near the NFC antenna approach area of
the wireless unit and click the [Confirm] button.
When [Edit password] is selected, a window for changing the password is displayed. Change to any
suitable password.
When the NFC reader / writer is held over the wireless unit, an error message may appear, such as "Device
driver software was not successfully installed" or "Smart card was not identified" depending on the version of
Windows OS. The reader / writer can be continuously used.
Refer to the Microsoft website (https://support.microsoft.com/kb/976832/).
Password at the time of shipment: admin
-17-
No.EX##-OMV0017-G
