VisuNet FLX System

Appendix

10
Appendix
1
Figure 10.1
Spare Parts
No.
(1)
(2)
(3)
(4)
(5)
(6)
-
-
-
2
3
4
12
VisuNet FLX System - possible configurations
Type code
DPU3200-22GT-304A-V1-
N0
DPU3200-22FC-304A-V1-
N0
BPC3200-*
DMU3200-22GT-V1-N0
DMU3200-22FC-V1-N0
PS1000-A6-24.5
SPAREPART-AG-320S-
BP-P1
SPAREPART-AG-320S-
BP-H1
SPAREPART-AG-320S-
SPACERS
SPAREPART-AG-320S-
BP-P1
5
6
7
8
13
14
Item No.
Description
70128300
21.5" Display (Full HD) - Display option
"22GT" with capacitive touch screen
70128301
21.5" Display (Full HD), optically bonded
- Display option "22FC" with capacitive
touch screen
must be con-
available as thin client or PC configura-
figured
tion
70128304
Compatible with display N° 1
70128305
Compatible with display N° 2
70103517
AC power supply Option
TBD
Spare part housing with 0.8-μm surface
70136528
Spare part housing blind plugs Standard
- 15x M20 Ex-rated blind plugs for hous-
ing
- Material: Nickel-plated brass
70136527
Spare part housing spacers &- 6x M5x80
mm & 8x M5x25 mm
- spacer nuts to affix display unit in enclo-
sure
70136529
Spare part housing blind plugs - GMP
- 15x M16 Ex-rated blind plugs for hous-
ing
- 2x M5 GMP screws for mounting scan-
ner holder
- Material: Stainless Steel
9
10
11
113
