VisuNet FLX System
Mechanical Installation
Figure 4.17
No.
1
2
3
4
Note
To get the cables through the cable glands, the insulation must be in place. Remove the
insulation only inside the housing.
Description
Size
Dual Ethernet
M16 (Ø 6-10 mm)
Dual Ethernet
M16 (Ø 3-7 mm)
Power
M20 (Ø7-12mm)
Spare for additional
M20 (Ø7-12mm)
connection
43
