11.1 Example 1
The following example uses assembly objects 101d/151d (mixed mode) and
results in the following:
The following prerequisites must be fulfilled:
Setting connection parameters
These parameters are configured on the PLC:
Assembly instance
Input: 151
Output: 101
Configuration: 112
(this value is used for all input/output
instances)
Setting tag type IPC02 on channels 1 and 3
Send a Change tagcommand to channel 1 as an implicit command:
Byte no.
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
...
Byte 11
A command confirmation appears in the input field:
Byte no.
Byte 0
Byte 1
72
Setting the data carrier IPC02 on channel 1 and channel 3.
■
Reading the read only code from an IPC02 data carrier.
■
Implicit communication.
■
One type IPH-XX R/W head is connected to channel 1 and channel 3 on
■
the IDENT Control.
One type IPC02 data carrier is located in front of each R/W head.
■
The MAC address on the IDENTControl is set to '01' (see chapter 6.5).
■
The device is connected to the network.
■
Use
Command code
Channel/Toggle bit
Tag type (high byte)
Tag type (low byte)
Use
Command code
Number of double words/
Channel/Toggle bit
Size (32 bits)
3
3
0
(this value is used for all input/output
instances)
Contents Description
04h Command CT (Change tag)
02h Channel = 1
Toggle bit = 0
30h IPC 02
32h IPC 02
00h
Contents Description
04h Command CT (Change tag
type)
02h Channel = 1
Toggle bit = 0
