VisuNet FLX System

Mechanical Installation

4 Mechanical Installation
Note
Recommendation for use: Carry out the installation of the device at the installation location with
at least 2 persons.
4.1

Installation Requirements

Note
It is recommended to orient the device so that the display faces north. If the device is facing
east or south, make sure that the sunshields adequately protect the display from direct sunlight.
Use optional sun shields to protect device from direct sunlight.
Caution!
It is not recommended to install the device in a way that the display is facing west.
If the device is facing west, direct sunlight when the sun is setting can penetrate the display
with a high ambient temperature.
Note
Use sunshields to further improve thermal heat reflection.
Caution!
Device damage!
Mount the device in such a way that it is protected from ultraviolet radiation and sunlight. Do not
expose the device to direct sunlight! The device might get damaged.
Caution!
Device damage!
Protect the device from external heat sources (e.g sunlight).
Note
Always try to use the installation in a shaded location if possible.
Caution!
Use of the device!
The use of the device is only permitted under the ambient conditions (temperature, humidity,
vibration and shock) which are specified in the technical data. Failure to comply with any of
these conditions void the warranty for the device. Pepperl+Fuchs cannot be held liable for any
damage arising from improper use and handling.
Caution!
Damage caused by condensation!
If the temperature of the device is different to that of the room in which it is located, condensa-
tion can form.
Switch on the device only if it has acclimated to the ambient temperature!
26
