VisuNet FLX System
Electrical Installation
Equipotential bonding connection the AG-XX00 Housing to PEDESTAL-
AG3200-*
The pedestals come with a preinstalled equipotential bonding cable.
1.
Connect the equipotential bonding cable from the upper part of the pedestal via grub screw to
the equipotential bonding rod of the adapter plate. Tighten the PE hardware to 4.0 Nm.
Figure 5.4
Warning!
This is not valid if you use an already installed/old VisuNet pedestal.
Refer to the corresponding manual.
