VisuNet FLX System
Mechanical Installation
4.11
Top sunshield installation instructions
Follow the installation instructions see chapter 4.1 to avoid damage to the device.
Note
If only using the top sunshield it is recommended to rotate the top sunshield down when not in
use to ensure further protection of the device.
Figure 4.31
54
