VisuNet FLX System
Mechanical Installation
4.12
Side, top and back sunshield installation instructions
Figure 4.36
1.
Pre-assemble the top sunshield as shown in the figure.
Figure 4.37
Item
1
2
3
4
QTY
Description
1
Sunshield top
1
Sunshield Mounting
Bracket, left
1
Sunshield Mounting
Bracket, right
4
M8 lock nut
Part-No.
-
-
-
311489
59
