VisuNet FLX System
Mechanical Installation
4.7
Installing Cables in the Pedestal
Warning!
Pinched cables!
Ensure that cables do not get pinched or damaged during installation.
Note
Refer to the manuals of the individual components for information on electrical installation and
wiring.
Required Installation Tools
•
Cable gland installation tool
•
Small cable ties
•
Side cutters
All tools should be torque controlled if a torque is specified.
Figure 4.11
Pedestal with two Cable Glands
No.
1
2
38
Opening size
M20
M16
